Products
h-kingAW45-skid-steer-loader
ModelAW45
Operating load (kg)700
Max Speed（km/h）10
Rated flux (L/min)80
Tire（track） model10-16.5NHS
Rated power (Kw)36.7KW
Fuel tank capacity (L)70
dead weight (kg)2916
self weight bucket (kg)2700
Bucket capacity (m³)0.4
Overall operating height (mm)4042
Height to bucket hinge pin (mm)3079
Hheight to top of cab (mm)2230
Height to bottom of level bucket(mm)2909
Without bucket length（mm）2325
Overall length with bucket(mm)3276
Dumping angle at maximum height(° )37.5
Dumping height(mm)2342
Dumping reach(mm)550
Rollback o bucket on ground(° )20.5
Rollback of bucket at full height(° )96.5
Wheelbase(mm)991
Ground clearance(mm)185
Angle of departure(° )20
Front turning radius without bucket(mm)1188
Front tuning radius(mm)2209.5
Rear tuning radius(mm)1481.5
Rear axle to bumper (mm)929
Tread width (mm)1462.5
Width (mm)1726.5
Bucket width (mm)1742
Brand: H-King AW45
Products
Small wheel loader
SPECIFICATIONS:
1.Engine
(1) Model: ZN390Q
(2) Rated Power:25KW
(3) Rated Speed: 2400 r/min(rpm)
2.0 Transmission System
(1) Type: Fixed-spindle Power shift
(2) Shift gear control oil pressure: 1.0-1.2MPa
(3) Rated input speed: 2600 (rpm)
3.0 Basic Parameters
(1) Overall weight : 2500kg
(2) LXWXH(mm): 4600X1600X2580mm
(3) Rated load :800kg
(4) Dumping height :2200mm
(5) Lifting height :2650mm
(6) Dump distance: 700mm
4.0 Bucket
(1) Bucket Capacity: 0.4 m3
(3) Bucket type: Heavy-duty bolt on teeth
(4) Max. Breakout Force: 20.8KN
5.0 Operating Specifications
(1) Steering System: Articulated Frame with hydraulic power steering
(2) Min Turning Radius: 3200mm
(3) Driving System: Hydraulic converter
6.0 Brake System
(1) Service Brake: Four Wheel Hydraulic spread-shoed brake
(2) Parking Brake: Hand operated
7.0 Tyre: 31x15.5-15
8.0 Wheelbase: 1950mm
9.0 Track: 1380 mm
Brand: H-king908
Products
H-KingAT50 Skid steer loader
ModelAT50
Operating load (kg)700
Max Speed（km/h）10
Rated flux (L/min)80
Tire（track） model300X52.5
Rated power (Kw)45KW
Fuel tank capacity (L)50
dead weight (kg)3224
self weight bucket (kg)2800
Bucket capacity (m³)0.4
Overall operating height (mm)3660
Height to bucket hinge pin (mm)2730
Hheight to top of cab (mm)2349
Height to bottom of level bucket(mm)2500
Without bucket length（mm）2170
Overall length with bucket(mm)3150
Dumping angle at maximum height(° )40
Dumping height(mm)1990
Dumping reach(mm)1040
Rollback o bucket on ground(° )30
Rollback of bucket at full height(° )100
Wheelbase(mm)1230
Ground clearance(mm)230
Angle of departure(° )18.5
Front turning radius without bucket(mm)1064
Front tuning radius(mm)1825
Rear tuning radius(mm)1264
Rear axle to bumper (mm)590
Tread width (mm)1022
Width (mm)1422
Bucket width (mm)1700
Brand: H-KingAT50
